Innolux lcd display 10.4inch 640*480 G104V1-T03 Rev.C3
G104V1-T03 Rev.C3 Datasheets Download
Name: G104V1-T03 Rev.C3.pdfType
LCD PANEL
Brand
Innolux
Model
G104V1-T03 Rev.C3
Innolux lcd display 10.4inch 640*480 G104V1-T03 Rev.C3
| Model: | G104V1-T03 Rev.C3 | Panel-type: | TFT-LCD, LCM |
| Size: | 10.4 inch | Resolution: | 640(RGB)×480 [VGA] 76PPI |
| Display Area: | 211.2(H)×158.4(V) mm | Outline Size: | 225.5(H)×176.3(V) ×9.34(D) mm |
| Brightness: | 500 cd/m² (Typ.) | Contrast Ratio: | 1500:1 (Typ.) (TM) |
| Viewing Angle: | 88/88/88/88 (Typ.)(CR≥10) | Display Mode: | Super MVA, Normally Black, Transmissive |
| Display Colors: | 262K 55% NTSC | Response Time: | 14/9 (Typ.)(Tr/Td) |
| Signal Interface: | CMOS/TTL (1 ch, 6-bit) , 31 pins Connector | Backlight type: | WLED , 50K hours , With LED Driver |
| Touch Screen: | without | Operating Temp.: | -30 ~ 80 °C |
Innolux lcd display 10.4inch 640*480 G104V1-T03 Rev.C3
| Model: | G104V1-T03 Rev.C3 | Panel-type: | TFT-LCD, LCM |
| Size: | 10.4 inch | Resolution: | 640(RGB)×480 [VGA] 76PPI |
| Display Area: | 211.2(H)×158.4(V) mm | Outline Size: | 225.5(H)×176.3(V) ×9.34(D) mm |
| Brightness: | 500 cd/m² (Typ.) | Contrast Ratio: | 1500:1 (Typ.) (TM) |
| Viewing Angle: | 88/88/88/88 (Typ.)(CR≥10) | Display Mode: | Super MVA, Normally Black, Transmissive |
| Display Colors: | 262K 55% NTSC | Response Time: | 14/9 (Typ.)(Tr/Td) |
| Signal Interface: | CMOS/TTL (1 ch, 6-bit) , 31 pins Connector | Backlight type: | WLED , 50K hours , With LED Driver |
| Touch Screen: | without | Operating Temp.: | -30 ~ 80 °C |
Quality Assurance:
Quality is our culture!
We will take each customer's order seriously and responsibly.
Each item will be tested ok by testing tools before shipment .
Warranty of Products:
90days for new products ,60days for secondhand products.
After you receive the parcel , remember to install it on your equipment in time .
If there is any problems in warranty period , pls contact us firstly, we will solve the problems for customer.
Guarantee of delivery:
Time is money!
It will take 1 working day for stock products , 2-3 working days for order products.
If there are special circumstances on delivery time, we will inform customer in time.
Service Guarantee:
We have a professional pre-sales and after-sales team to provide customers with good service.
we trust we will be your trustworthy supplier in china if we have a chance to serve you.
we trust we will be your trustworthy supplier in china if we have a chance to serve you.
Exchange / Return Policy:
We accept exchange or return within 7days if the goods you received has problems.
About refund, We need to check the goods whether is in the same condition we sent after we received the return, if no problems , we will refund .
Contact us:
About refund, We need to check the goods whether is in the same condition we sent after we received the return, if no problems , we will refund .
Contact us:
Mobile/Whatsapp: +86 138 2744 1621
Wechat : Invshop168
Skype : candychen88
Email : winnihk88@winnihk.com
invshop@163.com
Innolux lcd display 10.4inch 640*480 G104V1-T03 Rev.C3
| Model: | G104V1-T03 Rev.C3 | Panel-type: | TFT-LCD, LCM |
| Size: | 10.4 inch | Resolution: | 640(RGB)×480 [VGA] 76PPI |
| Display Area: | 211.2(H)×158.4(V) mm | Outline Size: | 225.5(H)×176.3(V) ×9.34(D) mm |
| Brightness: | 500 cd/m² (Typ.) | Contrast Ratio: | 1500:1 (Typ.) (TM) |
| Viewing Angle: | 88/88/88/88 (Typ.)(CR≥10) | Display Mode: | Super MVA, Normally Black, Transmissive |
| Display Colors: | 262K 55% NTSC | Response Time: | 14/9 (Typ.)(Tr/Td) |
| Signal Interface: | CMOS/TTL (1 ch, 6-bit) , 31 pins Connector | Backlight type: | WLED , 50K hours , With LED Driver |
| Touch Screen: | without | Operating Temp.: | -30 ~ 80 °C |
Customer's Reviews:
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Great
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Great deal! Would buy from again
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Excellent, many thanks
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
NO PROBLEM. GOOD WORK
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Fast delivery
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Worked Great
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Good quality products
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
good
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
item as described and packaged well
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Order received in good condition. Would definitely use this seller again for any future orders.
G104V1-T03 Rev.C3 Summary
It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Panelook in the following: Wide Temperature, Lamp Repaceable, WLED Backlight, Life ≥ 50K hours, With LED Driver, 180° Reverse, Matte .
